Part Number:

Description: The 800G OSFP DR8 transceiver is a high-quality optical transceiver designed for utilization in 800 Gigabit Ethernet links over 500 meters of single-mode fiber. The transceiver features 8 independent electrical input/output channels, operating at speeds of up to 106.25 Gbps per channel. This transceiver consists of two transmitter/receiver units, each operating on a set of wavelengths on the ITU G.694.2 CWDM grid at 1310 nm. The electrical interface of the transceiver complies with the 800GAUI-8 standard defined by IEEE 802.3ck, and is also compliant with the OSFP MSA. It is suitable for various network applications, including Internet Protocol switches and routers

Date Rate: 800G

Component: EML+PIN

Rec. Sens: -3.9dBm

Case Temp: C

Multi Rate: N

Category: 800G

Package: OSFP

Wavelength: 1304.5nm~1317.5nm

Output Power: -2.9~+4dBm

Connector: MPO

Reach: 500m

Application: 800G Ethernet, Data Center Switch, Data Center Interconnect
