Part Number:

Description: The 25G SFP28-LWDM (LAN-WDM) uses 12 wavelengths covering 1269.23nm～1318.35nm of O-band with a transmission data rate of 28Gbps, supporting link distance up to 40km of G.652 single-mode fiber. Compatible with SFF-8431, SFF-8432 and supporting Wireless (CPRI/eCPRI) and 25G Ethernet, this transceiver is ideally suited for 5G fronthaul applications. Digital diagnostics functions are available via an I2C interface, as specified by SFF-8472 and SFF-8402.

Date Rate: 25.78G

Component: DFB/PIN

Rec. Sens: -14dBm

Case Temp: C/I

Multi Rate: Y

Category: 25G

Package: SFP28

Wavelength: 1269.23~1318.35nm

Output Power: 0~+6dBm

Connector: LC

Reach: 10KM

Application: 25G Ethernet, CPRI/eCPRI
