Part Number:

Description: The 200G QSFP56 SR4 transceiver is an integrated module with micro-optic and semiconductor components, facilitating optical-electrical and electrical-optical conversions. Designed as a four-channel, pluggable, parallel QSFP56 transceiver for 200Gbps fiber communication, each channel can operate at 53Gbps up to 100m on OM4 fiber with an operating wavelength of 850nm. The optical interface uses a 12-fiber MTP(MPO) connector, and the electrical interface employs a 38-contact edge-type connector. This 200G SR4 module complies with the 200GBASE-SR4 standard of IEEE802.3cd, providing reliable, long-life, high-performance, and consistent service.

Date Rate: 200G

Component: VCSEL+PIN

Rec. Sens: -6.5dBm(OMA)

Case Temp: C

Multi Rate: N

Category: 200G

Package: QSFP56

Wavelength: 850nm

Output Power: -6.5~+4dBm

Connector: MPO

Reach: 70M(OM3)/100M(OM4)

Application: 200 Gb/s Ethernet, Data Center Interconnect
