Part Number:

Description: The 400G QSFP-DD FR4 CWDM 2km Transceiver is a high-quality 400G FR4 module designed for 2km optical communication applications and is compliant with the 100G Lambda MSA standard. This QSFP-DD module can convert 8-channel 53.125 GB/s electrical data to 4-channel 106.25 GB/s optical signals and multiplex them into a single channel for 425 GB/s optical transmission. Similarly, it optically demultiplexes a 425 GB/s input into 4-channel signals and converts them to 8-channel output electrical data on the receiver side, accessible via a two-wire serial interface

Date Rate: 400G

Component: EML/PIN

Rec. Sens: -4.6dBm

Case Temp: C

Multi Rate: N

Category: 400G

Package: QSFP-DD

Wavelength: 1271nm~1331nm

Output Power: -3.3~+3.5dBm

Connector: LC

Reach: 2KM

Application: Data Center Interconnect
